Delta ASD-A2R-0221 Series User Manual

Chapter 2 InstallationASDA-A2R Series
Revision December, 2014
2-11
according to different load inertia or speed. The following is the calculation method.
m represents load / motor inertia ratio.
Allowable frequency =
Allowable frequency when servo motor run without load
m + 1
x
Rated speed
Operating speed
times
min.
2
The comparison table of external regenerative resistor is provided below. Please
choose the appropriate regenerative resistor according to the allowable frequency.
The table below describes the suggested allowable frequency (times/min) of
regenerative resistor when the servo drive runs without load.
Allowable frequency of regenerative resistor when the servo drive runs without load
(times/min)
Motor Capacity
Corresponding
Motor
ECMA
□□
C
100 W 200 W
400 W
(F60)
400 W
(F80)
750 W 1.0 kW 2.0 kW
01 02 04 04 07 10 20
BR400W040 (400 W 40Ω) - - 8608 3506 2110 925 562
BR1K0W020 (1 kW 20Ω) - - - 8765 5274 2312 1406
Motor Capacity
Corresponding
Motor
ECMA
□□
E
0.5 kW 1 kW 1.5 kW
2.0 kW
(F130)
2.0 kW
(F180)
3.0 kW
05 1.0 15 20 20 30
BR400W040 (400 W 40Ω) 291 283 213 163 68 -
BR1K0W020 (1 kW 20Ω) 729 708 533 408 171 -
BR1K5W005 (3 kW 10Ω) - - - - - 331
Motor Capacity
Corresponding
Motor
ECMA
□□
F
3.0 kW
30
BR1K5W005 (3 kW 10Ω) 331
Allowable frequency of regenerative resistor when the servo drive runs without load
(times/min)
