Delta DVP-SS2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-16
Special
M
Function
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
M1044
Zero point condition
○ ○ ○ ○
OFF
-
OFF
R/W
NO
OFF
M1045
Disable “all output reset” function
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1046
Indicate STL status
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1047
Enable STL monitoring
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1048
Indicate alarm status
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1049
Enable alarm monitoring
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1050
Disable interruption I000 / I001
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1051
Disable interruption I100 / I101
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1052
Disable interruption I200 / I201
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1053
Disable interruption I300 / I301
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1054
Disable interruption I400 / I401
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1055
Disable interruption I500 / I501
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1056
Disable interruption I600~I699
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1057
Disable interruption I700~I799
Disable interruption I805~I899 (V2.00 and
above are supported.)
○ ○ ○ ○
OFF - - R/W NO OFF
M1058 COM3 monitor request
ES2/
EX2
╳ ○ ○
OFF - - R/W NO OFF
M1059
Disable high-speed counter interruptions
I010~I080
○ ○ ○ ○
OFF - - R/W NO OFF
M1060
System error message 1
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1061
System error message 2
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1062
System error message 3
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1063
System error message 4
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1064
Incorrect use of operands
○ ○ ○ ○
OFF
OFF
-
R
NO
OFF
M1065
Syntax error
○ ○ ○ ○
OFF
OFF
-
R
NO
OFF
M1066
Loop error
○ ○ ○ ○
OFF
OFF
-
R
NO
OFF
M1067*
Program execution error
○ ○ ○ ○
OFF
OFF
-
R
NO
OFF
M1068*
Execution error locked (D1068)
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1070
Switching clock pulse of Y1 for PWM
instruction (ON: 100us; OFF: 1ms)
ES2/
EX2
○ ○ ○
OFF - - R/W NO OFF
M1071
Switching clock pulse of Y3 for PWM
instruction (ON: 100us; OFF: 1ms)
ES2/
EX2
○ ○ ○
OFF - - R/W NO OFF
M1072
PLC status (RUN/STOP), ON = RUN
○ ○ ○ ○
OFF
ON
OFF
R/W
NO
OFF
M1075
Error occurring when write in Flash ROM
○ ○ ○ ○
OFF
-
-
R
NO
OFF
M1077* Real-time clock is out of order.
ES2/
EX2
○ ○ ○
OFF - - R NO OFF
M1078
Y0/CH0(Y0, Y1) pulse output pause
(immediate)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1079 Y1 pulse output pause (immediate)
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1080
COM2 monitor request
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1081
Changing conversion mode for FLT
instruction
○ ○ ○ ○
OFF - - R/W NO OFF
M1083*
Selecting X6 pulse-width detecting mode.
M1083 = ON, detecting pulse-width when
X6 = ON; M1083 = OFF, detecting pulse-
width when X6 = OFF.
ES2/
EX2
○ ○ ○
OFF - - R/W NO OFF
M1084*
Enabling X6 Pulse width detecting
function. (has to be used with M1083 and
D1023)
ES2/
EX2
○ ○ ○
OFF OFF OFF R/W NO OFF
M1085
Selecting DVP-PCC01 duplicating function
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1086
Enabling password function for DVP-
PCC01
○ ○ ○ ○
OFF - - R/W NO OFF
M1088
Matrix comparison.
Comparing between equivalent values
(M1088 = ON) or different values (M1088
= OFF).
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1089
Indicating the end of matrix comparison.
When the comparison reaches the last bit,
M1089 = ON.
○ ○ ○ ○
OFF OFF - R NO OFF
M1090
Indicating start of matrix comparison.
When the comparison starts from the first
bit, M1090 = ON.
○ ○ ○ ○
OFF OFF - R NO OFF
M1091
Indicating matrix searching results. When
the comparison has matched results,
○ ○ ○ ○
OFF OFF - R NO OFF
