Delta DVP-SS2 User Manual

2. Programming Concepts
2-17
Special
M
Function
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
comparison will stop immediately and
M1091 = ON.
M1092
Indicating pointer error. When the pointer
Pr exceeds the comparison range, M1092
= ON
○ ○ ○ ○
OFF OFF - R NO OFF
M1093
Matrix pointer increasing flag. Adding 1 to
the current value of the Pr.
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1094
Matrix pointer clear flag. Clear the current
value of the Pr to 0
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1095
Carry flag for matrix rotation / shift /
output.
○ ○ ○ ○
OFF OFF - R NO OFF
M1096
Borrow flag for matrix rotation/shift/input
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
M1097
Direction flag for matrix
rotation/displacement
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1098
Counting the number of bits which are “1”
or “0”
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1099
ON when the bits counting result is “0”
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
M1102*
Y2/CH1 (Y2, Y3) pulse output execution
completed
○ ○ ○ ○
OFF - - R/W NO OFF
M1103* Y3 pulse output completed
ES2/
EX2
○ ○ ○
OFF - - R/W NO OFF
M1104
Y2/CH1 (Y2, Y3) pulse output pause
(immediate)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1105 Y3 pulse output pause (immediate)
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1106
When M1106=ON, set the zero point for
the first DZRN auto-reset (Y0, Y1) to the
position wher DOG point stops on the
positive direction. (If M1106 is OFF, it
stops on the negative direction.)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1107
When M1107=ON, set the zero point for
the first DZRN auto-reset (Y0, Y1) to the
position wher DOG point stops on the
positive direction. (If M1107 is OFF, it
stops on the negative direction.)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1108
Y0/CH0 (Y0, Y1) pulse output pause
(ramp down)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1109 Y1 pulse output pause (ramp down)
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1110
Y2/CH1 (Y2, Y3) pulse output pause
(ramp down)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1111 Y3 pulse output pause (ramp down)
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1112
Switching clock pulse of Y0 for PWM
instruction (ON: 100us; OFF: 1ms)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1113
Switching clock pulse of Y2 for PWM
instruction (ON: 100us; OFF: 1ms)
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1116
Enable high-speed output of Y0/Y2 for
PWM instruction (unit: 1 us) available for
ES2: V3.00, SS2: V2.80, SA2: V2.60,
12SE: V2.02, 26SE: V1.02, SX2: V2.40
or later
ES2/
EX2
○ ○ ○
OFF OFF OFF R/W NO OFF
M1117
Enable high-speed output of Y1/Y3 for
PWM instruction (unit: 1 us) available for
ES2: V3.00, SS2: V2.80, SA2: V2.60,
12SE: V2.02, 26SE: V1.02, SX2: V2.40
or later
ES2/
EX2
○ ○ ○
OFF OFF OFF R/W NO OFF
M1119*
Enable 2-speed output function of
DDRVI/DDRVA instructions; refer to
section 2.16 for the usage
○ ○
SA2
26SE
○
OFF OFF OFF R/W NO OFF
M1120*
Retaining the communication setting of
COM2 (RS-485), modifying D1120 will be
invalid when M1120 is set.
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1121
For COM2(RS-485), data transmission
ready
○ ○ ○ ○
OFF OFF - R NO OFF
M1122
For COM2(RS-485), sending request
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
M1123
For COM2(RS-485), data receiving
completed
○ ○ ○ ○
OFF OFF - R/W NO OFF
M1124
For COM2(RS-485), data receiving ready
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
