Delta DVP-SS2

3. Instruction Set
3-565
API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
266 D BOUT Output Specified Bit of a Word
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BOUT: 5 steps
DBOUT: 9 steps
D
*
*
*
*
*
*
n
*
*
*
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
Operands:
D: Destination output device n: Device specifying the output bit
Explanations:
5. For ES2/EX2 models, only V1.20 or above supports the function.
Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
BOUT instruction performs bit output on the output device according to the value specified by
operand n.
Status of Coils and Associated Contacts:
Evaluation result
BOUT instruction
Coil
Associated Contacts
NO contact（normally open）
NC contact（normally closed）
FALSE
OFF
Current blocked
Current flows
TRUE
ON
Current flows
Current blocked
Program Example:
X0 X1
BOUT K4Y0 D0
Instruction: Operation:
LDI X0 Load NC contact X0
AND X1 Connect NO contact
X1 in series.
BOUT
K4Y0 D0 When D0 = k1,
executes output on Y1
When D0 = k2,
executes output on Y2
