DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-572
API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
273 D BOR
Connect NO Contact in Parallel
by Specified Bit
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BOR: 5 steps
DBOR: 9 steps
S
*
*
*
*
*
*
n
*
*
*
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
Operands:
S: Reference source device n: Reference bit
Explanations:
1. For ES2/EX2 models, only V1.20 or above supports the function.
2. Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
BOR instruction is used to connect NO contact in parallel, whose state is defined by the reference
bit n in reference device D, i.e. if the bit specified by n is ON, the NO contact will be ON, and
vice versa.
Program Example:
X0
Y1
BOR D0 K0
Instruction: Operation:
LD X0 Load NO contact X0
BOR
D0 K0 Connect NO contact in
parallel, whose state is
defined by bit0 of D0
OUT Y1 Drive coil Y1
