DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-648
15. Descriptions on the Flags / Devices
Flags / Devices
Default Descriptions
M1620 OFF
OFF CAN V2.0B protocol
ON  CAN V2.0A protocol
M1621 / M1622
OFF/OFF
OFF/OFF  master mode: waiting to receive after
sending; if you only need to send data, you can stop
executing this instruction in the next scan.
After sending is done, the slave response time should be
longer than a scan cycle.
OFF/ON  master mode: after sending in broadcast
mode, receives data from multiple slaves until timeout
occurs.
ON/OFF  slave mode: sending data, after receiving is
done.
ON/ON  slave mode: only receiving in broadcast mode
without responses
M1623 OFF
ON: communication error; PLC clears this flag when you
start the instruction again.
D1175 0
The accumulated packet number (slave number) in the
broadcast mode; this number will be accumulated during
execution. You can use this number when the completion
flag is ON. Up to 100 slaves can be counted, when
exceeding 100, the program does not save and stops
counting.
D1177 200
Timeout setting; the unit is ms. When
the value is set to 0,
it indicates this function is disabled until this instruction
stops executing.
When the mode is in master broadcast, the ti
meout value
cannot be 0. If the timeout value is 0, the system
automatically adjusts this value to 200. When timeout
occurs, it indicates the broadcast communication is over.
16. The instruction supports the following series and firmware versions
Series
12SA2/
20SX2
12SE 26SE 32ES2-C COPM-SL
FW
Version
V3.02 V1.88 V2.02 V3.60 V1.40
