3. Instruction Set
3-651
Example 2
System set: DVP12SA211T + DVPCOPM-SL
Mode: Master mode (receiving data from all slaves after sending data in broadcast mode)
Communication packets:
PLC program design:
Step 1) SET M1620  2.0A protocol
Step 2) RST M1621 and SET M1622  Master mode; receiving packets from all slaves after
sending in broadcast mode; set timeout to 200 ms; if no packets is received in a period of
200 ms, the communication is over.
Step 3) LDP M0  set up MsgId (0x050), data length and data
