DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-688
API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
350 D PUJOG Module~ErrCode
PU module jog output
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F DPUJOG: 25 steps
(To be used in ISPSoft)
Module * * *
Axis * * *
JogSpeed * * *
Busy * * *
Error * * *
ErrCode *
PULSE
16-bit
32-bit
ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2
Operands:
Module: Module number Axis: Output axis number JogSpeed: Jog output frequency
Busy: Output in execution Error: Error flag ErrCode: Error code
Explanations:
1. This instruction is available for ES2/EX2 (FW V4.02 or later) and ES2-E (FW V1.48 or later).
For ISPSoft, we recommend using software version 3.16 and above. When En setting is set to
ON, this instruction would be effective. Once the setting changes to OFF, Output pulse would
be terminated immediately. WPLSoft does NOT support this instruction.
2. Module sets the serial number of modules at the right of the PLC. The first one is number 0,
the second one is number 1 and so on. Whatever modules at the right of the PLC must be
numbered. The maximum number is 8. The instruction is exclusive to the PU modules at the
right of the PLC. If the specified module is not a PU module, the error flag Error will change to
ON.
3. Axis sets the output axis number for the specified PU module. The setting values 1~2
represent the axis1~axis2 output of the specified PU module respectively. If the PU module
has no corresponding axis number for output, the error flag Error will change to ON.
4. JogSpeed sets the jog output frequency. The setting value is a signed 32 bit value within the
range of -200,000 (-200K) ~200,000 (200K) (Hz). When the value is greater than 0, the output
will go in the positive direction (and the direction output point is off). When the value is less
than 0, the output will go in the negative direction (and the direction output point is on). When
the value is 0, the output will stop.
5. The instruction can be used for the speed change. While the instruction is being executed, you
can change the value of TarSpeed so as to change the output speed. When the setting value
