DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-60
1. M1029 = ON when Y0 pulse output completes.
2. M1030 = ON when Y1 pulse output completes
3. M1102 = ON when Y2 pulse output completes.
4. M1103 = ON when Y3 pulse output completes.
5. When PLSY, PLSR instruction are OFF, M1029, M1030, M1102, M1103 will be OFF as well.
When pulse output instructions executes again, M1029, M1030, M1102, M1103 will be OFF
and turn ON when execution completes.
6. Users have to clear M1029 and M1030 manually.
INCD:
M1029 will be “ON” for a scan period when the assigned groups of data comparison is completed
RAMP, SORT:
1. M1029= ON when instruction is completed. M1029 must be cleared by user manually.
2. If this instruction is OFF, M1029 will be OFF.
DABSR:
1. M1029= ON when instruction is completed.
2. When the instruction is re-executed for the next time, M1029 will turn off first then ON again
when the instruction is completed
ZRN, DRVI, DRVA:
1. M1029 will be “ON” after Y0 and Y1 pulse output is completed. M1102 will be “ON” after Y2
and Y3 pulse output is compeleted.
2. When the instruction is re-executed for the next time, M1029 / M1102 will turn off first then ON
again when the instruction is completed.
Function Group
Clear Instruction
Number
M1031, M1032
Contents:
M1031 (clear non-latched memory), M1032 (clear latched memory)
Device
Devices will be cleared
M1031
Clear non-latched area
Contact status of Y, general-purpose M and general-purpose S
 General-purpose contact and timing coil of T
 General-purpose contact, counting coil reset coil of C
 General-purpose present value register of D
 General-purpose present value register of T
 General-purpose present value register of C
M1032
Clear latched area
Contact status of M and S for latched
 Contact and timing coil of accumulative timer T
 Contact and timing coil of high-speed counter C for latched
 Present value register of D for latched
 Present value register of accumulative timer T
 Present value register of high-speed counter C for latched
Function Group
Output State Latched in STOP mode
Number
M1033
Contents:
When M1033 = ON, PLC outputs will be latched when PLC is switched from RUN to STOP. If the
data is in non-latched area, it cannot be cleared to zero.
Function Group Disabling all Y outputs
Number M1034
Contents:
When M1034 = ON, all outputs will turn off.
Function Group
RUN/STOP Switch
Number
M1035
Contents:
When M1035 = ON, PLC uses input point X7 as the switch of RUN/STOP.
