Delta DVP-SS2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
C-6
Special
D
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
00: Voltage mode
01: Current mode (0~20mA)
11: Current mode (4~20mA)
Setting the mode of output:
00: Voltage mode
01: Current mode
D1115*
Analog input/output mode setting (available for TP70P)
- - - R/W YES 0
D1116*
Output value of analog output channel 0 (DA 0)
0 0 0 R/W NO 0
D1117*
Output value of analog output channel 1 (DA 1)
0 0 0 R/W NO 0
D1118*
Sampling time of analog/digital converstion. Default: 2. Unit:
1ms. Sampling time will be regarded as 2ms if D1118≦2
2 - - R/W YES 2
D1120*
COM2 (RS-485) communication protocol
H’86 - - R/W NO H’86
D1121*
COM1(RS-232) and COM2(RS-485) PLC communication
address
- - - R/W YES 1
D1122
COM2(RS-485) Residual number of words of transmitting
data
0 0 - R NO 0
D1123
COM2(RS-485) Residual number of words of the receiving
data
0 0 - R NO 0
D1124
COM2(RS-485) Definition of start character (STX)
H’3A - - R/W NO H’3A
D1125
COM2(RS-485) Definition of first ending character (ETX1)
H’0D - - R/W NO H’0D
D1126
COM2(RS-485) Definition of second ending character
(ETX2)
H’0A - - R/W NO H’0A
D1129
COM2 (RS-485) Communication time-out setting (ms)
0 - - R/W NO 0
D1130
COM2 (RS-485) Error code returning from Modbus
0 - - R NO 0
D1137*
Address where incorrect use of operand occurs
0 0 - R NO 0
D1140
Number of Analog I/O modules (max. 1)
(# => 1: TP04P-22XA11R / TP70P-22XA11R /
TP04P-21EX11R/TP70P-21EX11R; 0: Other models)
- - - R NO #
D1167
The specific end word to be detected for RS instruction to
execute an interruption request (I140) on COM1 (RS-232).
0 - - R/W NO 0
D1168
The specific end word to be detected for RS instruction to
execute an interruption request (I150) on COM2 (RS-485)
0 - - R/W NO 0
D1169
The specific end word to be detected for RS instruction to
execute an interruption request (I160) on COM3 (RS-485)
0 - - R/W NO 0
D1182
Index register E1
0 - - R/W NO 0
D1183
Index register F1
0 - - R/W NO 0
D1184
Index register E2
0 - - R/W NO 0
D1185
Index register F2
0 - - R/W NO 0
D1186
Index register E3
0 - - R/W NO 0
D1187
Index register F3
0 - - R/W NO 0
