Load Cell Module DVP02LC-SL
DVP-PLC Operation Manual
14
CR#22, 23, 24, 25: CH1 to CH2 unit of measurement
Explanations:
These control registers record the units of measurement in hex values corresponding to the ASCII
words set up by the user. Each channel is able to contain maximum 4 ASCII words.
ASCII/hex table:
Hex 30 31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F
ASCII 0 1 2 3 4 5 6 7 8 9
⌧ ⌧ ⌧ ⌧ ⌧ ⌧
Hex 40 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E 4F
ASCII
⌧
A B C D E F G H I J K L M N O
Hex 50 51 52 53 54 55 56 57 58 59 5A 5B 5C 5D 5E 5F
ASCII P Q R S T U V W X Y Z
⌧ ⌧ ⌧ ⌧ ⌧
Hex 60 61 62 63 64 65 66 67 68 69 6A 6B 6C 6D 6E 6F
ASCII
⌧
a b C d e f g h i j k l m n o
Hex 70 71 72 73 74 75 76 77 78 79 7A 7B 7C 7D 7E 7F
ASCII p q r s t u v w x y z
⌧ ⌧ ⌧ ⌧ ⌧
Example: If you would like the unit for CH1 to be “gram”, set up CR#22 and CR#23 following the
figure below.
67H 72H61H 6DH
CR#2
CR#23
amgr
CR#26: Weight correction command
Explanations:
Commands for the user to correct weights.
Value Function
H’0001 CH1 reset to zero
H’0002 CH1 weight base point
H’0003 CH2 reset to zero
H’0004 CH2 weight base point
CR#33, 34: CH1 to CH2 weight base point
Explanations:
The weight of the weights has to be written in during the correction.
