Load Cell Module DVP02LC-SL
DVP-PLC Operation Manual
13
bit15 ~ 2 bit7 ~ 4 bit3 ~ 0
CH2 CH1
Reserved
H’0 = gross weight
H’1 = net weight
H’F = channel disabled
CR#8, 9: CH1 to CH2 tare weight
Explanations:
You can write in the weight or read it by commands. Default: K0. Range: K-32,768 to K32,767.
CR#10, 11: CH1 to CH2 average times
Explanations:
The range is 1 to 100. When the value exceeds 100, it will automatically be switched to 100. When it
falls below 1, it will automatically be switched to 1.
Range Default
1 ≤ average times ≤ 100 10
CR#12, 13: CH1 to CH2 average weight
Explanations:
The average weight is displayed.
CR#14, 15: CH1 to CH2 present weight
Explanations:
The present weight is displayed.
CR#16, 17: CH1 to CH2 times of standstill check
Explanations:
Default: K5. Range: K1 to K500. See 5.3.2 for details.
CR#18, 19: CH1 to CH2 range for standstill check
Explanations:
Default: K10. Range: K1 to K10,000. See 5.3.2 for details.
CR#20, 21: CH1 to CH2 decimal point place
Explanations:
The place of the decimal point set up by the user.
Range Default
0 ≤ decimal point place ≤ 4 2
