Delta DVP48ES300T User Manual

DVP-ES3 Series Operation Manual
5-34
_5

Mode 0:
Digital input
10V
5V
-5V
+
32000
-10V
-32000
+16000
0
Gain
Offset
Voltage
output
-32768
+32767
Mode 1 of CR#2 ~ CR#5
0mA ~ +20mA, Default: Gain = 16,000（= ）, Offset = 0
Range of digital conversion
0 ~ +32,000
Max./Min. range of digital
conversion
0 ~ +32,767

Mode 1:
Digital input
+32000+16000
20mA
10mA
0
Offset
Current
output
+32767
Gain
Mode 2 of CR#2 ~ CR#5
+4mA ~ +20mA, Default: Gain = 19,200（= ）， Offset = 6,400（=
）
Range of digital conversion
0 ~ +32,000
Max./Min. range of digital
conversion
0 ~ +32,767

Mode 2:
Digital input
+32000+16000
20mA
12mA
0
Offset
Current
output
+32767
Gain
4mA
-6400
