Chapter 6 Writing a Program
6-27
6.6.2
Downloading a Program and Parameters
If ISPSoft is correctly connected to a PLC, you can download the parameters and program in the project to the
PLC. First, start ISPSoft and open the project you created in the previous sections. In this example, you
download two types of parameters to the CPU module: hardware configuration and the program itself.
Downloading the hardware configuration
(1) Double-click HWCONFIG in the project management area to open the HWCONFIG window.
(2) The hardware configuration displays in the window. Before you download the hardware configuration
to the CPU module, make sure the actual hardware configuration is the same as the hardware
configuration in the window.
(3) On the Options menu, click Download, or on the toolbar. The Transfer Items dialog box
appears. Click OK to download the hardware configuration to the CPU module.
To Next Page
