Chapter 9 Ethernet Specification and Operation
9-51
*1 Communication Port Type
Communication Port Type Description
1 Self-defined
2 ControlNet
3 ControlNet Redundant
4 EtherNet/IP
5 DeviceNet
201 Modbus/TCP
203 SERCOS III
9.7.8 TCP/IP Interface Object (Class ID: F5 Hex)
This object provides the mechanism to configure a device’s TCP/IP network interface. Examples of configurable items
include the device’s IP Address, Network Mask, and Gateway Address.
Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
H’01 Get_Attributes_All X V Read all attributes
H’0E Get_Attribute_Single V V Read one attribute
H’10 Set_Attribute_Single X V Write one attribute
Class
Class ID = H’F5
Instance
H’00：Class Attribute
H’01：Instance Attribute
H’N: Instance #N Attribute, number of IP addresses that the device supported
When Instance = 0, the Class Attributes are listed below.
