Delta DVP48ES300T

DVP-ES3 Series Operation Manual
4-6
_4
4.3.1 Linking the CPU module and a module
Step 1: Use a flat head screwdriver to open the side cover on the CPU module for linking a module.
Step 2: Use a flat head screwdriver to release the I/O module securing clip.
Step 3: Connect the CPU module and the module with the I/O connecting ports.
