Delta M60U

120 Model
WB
①
⑧
⑥
④
⑤
⑦ ⑦⑩ ⑥
NO Location Screw torque
10
Mounting bracket 40.0 lbf-in (4.5N•m)
9
Wiring box fan 7.00 lbf-in (0.8N•m)
11
Communication cover 7.00 lbf-in (0.8N•m)
8
SPD board 14.6 lbf-in (1.6N•m)7
Ground of SPD board 6.90 lbf-in (0.8N•m)6
Grounding point 69.4 lbf-in (7.8N•m)5
Fuse holder 24.8 lbf-in (2.8N•m)
4 Wiring box cover 21.0 lbf-in (2.37N•m)
2
Grounding bar 26.0 lbf-in (3.0N•m)
1 AC switch 31.0 lbf-in (3.5N•m)
Conductor cross-section
-
-
12
Grounding screw terminal 80.0 lbf-in (9.0N•m) 1~2/0 AWG (35~50mm²)
-
-
-
-
14~8 AWG (2~8mm²)
-
6~4 AWG (14~22mm²)
13
14 Insulator cover 7.00 lbf-in (0.8N•m)
-
1~2/0 AWG (35~50mm²)
3 Communication port - 20 AWG (0.5mm²)
Mounting screw of grounding bar 22.0 lbf-in (2.5N•m) -
Appendix C-2: Assembly Note for 120 model
②
③
⑪
⑫ ⑫
⑬
⑭
⑨
124
Appendix C: Assembly Note
