Delta M60U

3.1.3.2 Old Models With New Version of Mounting Bracket
402.7mm [15.9in]
898mm [35.3in]
163.5mm [6.4in]
228mm [9.0in]
155mm [6.1in]
485.5mm [19.1in]
127.5mm [5in]
57mm [2.2in]
220.2mm [8.7in]
73mm [2.9in]
43.2mm [1.7in]
36mm [1.4in]
246mm [9.7in]
410mm [16.1in]
582mm [22.9in]
205.5mm [8.1in]
82mm [3.2in]
246mm [9.7in]
410mm [16.1in]
82mm [3.2in]
246mm [9.7in]
410mm [16.1in]
Figure 3-7: Mounting bracket dimensions for old models
30
Installation
