Delta M60U

Necessary for vertical mounting Necessary for horizontal mounting
Figure 3-6: Required position for at least 8 screws for new models
Figure 3-5: Mounting base plate and rear view for new models
102mm
[4in]
229.5mm [9in]485.5mm [19.1in]
715mm [28.1in]
870mm [34.3in]
155mm [6.1in]
