Delta M60U - New Models with New Version of Mounting Bracket

3.1.3.1 New Models With New Version of Mounting Bracket
Figure 3-4: Mounting bracket dimensions for new models
402.7mm [15.9in]
898mm [35.3in]
140.5mm [5.5in]
205mm [8.1in]
155mm [6.1in]
485.5mm [19.1in]
127.5mm [5in]
80mm [3.1in]
220.2mm [8.7in]
50mm [2.0in]
43.2mm [1.7in]
13mm [0.5in]
246mm [9.7in]
410mm [16.1in]
582mm [22.9in]
82mm [3.2in]
246mm [9.7in]
410mm [16.1in]
82mm [3.2in]
246mm [9.7in]
410mm [16.1in]
