27
Quick installation guide for solar inverters RPI M6A M8A M10A EU V4 EN 5013221703 00 2017-11-16
Mechanical details RPI M6A RPI M8A RPI M10A
Dimensions (W x H x D) 510 x 445 x 177 mm
Weight 25 kg 25 kg 26 kg
Cooling Natural convection
AC connection type Amphenol C16-3
DC connection type Multi-Contact MC4
Communication interfaces 2 x RS485, 1 x dry contact, 1 x EPO (E-Power off), 6 x digital inputs
General specications RPI M6A RPI M8A RPI M10A
Delta model name RPI M6A RPI M8A RPI M10A
Delta part number RPI602FA0E1000 RPI802FA0E1000 RPI103FA0E1000
Maximum efciency 98.3% 98.3% 98.3%
EU efciency 97.6% 97.9% 98.0%
Operating temperature range -25 ... +60 °C
Operating temperature range without derating -25 ... +40 °C
Storage temperature range -25 ... +60 °C
Relative humidity 0 ... 100%, non-condensing
Max. geographical operating height 2,000 m above sea level
Standards and guidelines RPI M6A RPI M8A RPI M10A
Protection degree IP65
Safety class I
Pollution degree II
Overload behavior Current limiting, power limiting
Safety IEC 62109-1/-2, CE-compliance
EMC EN 61000-6-2, EN 61000-6-3
Fault-free operation IEC 61000-4-2/-3/-4/-5/-6/-8
Harmonic distortion EN 61000-3-2 EN 61000-3-12
Fluctuations and brillations EN 61000-3-3 EN 61000-3-11
Grid interfaces
For Europe: see www.solar-inverter.com
For Australia/New Zealand: AS3100/AS4777
1)
When operating with symmetric DC inputs (50% / 50%)
2)
IEC 60664-1, IEC 62109-1
3)
The maximum AC apparent power species the maximum power that an inverter is able to supply. This maximum apparent power is not necessarily achieved.
4)
Limited to 4.99 kVA, when grid type AU/NZ PL 4.99k is selected.
5)
AC voltage and frequency range are programmed using the corresponding country specications.
Technical data
