15
LUBRICATION
1. DISCONNECT MACHINE FROM POWER SOURCE.
2. Remove the six screws (A) Fig. 30 that hold the top
cover in place, and remove the top cover.
3. The variable speed pulleys should be oiled weekly
with a few drops of light machine oil in the two oil holes
(B) Fig. 31, located on top of the variable speed pulleys.
IMPORTANT: Oil the holes when the drill press is
turned OFF. Then turn the machine ON and run
through the low and high speed ranges a few times.
Fig. 30
Fig. 31
A
A
B
B
MAINTENANCE
