Operation and installation manual SOLIVIA 2.5 EU G3
9 Technical data
* The maximum AC power value indicates the power
an inverter might be able to deliver. However, such a
maximum AC power may not necessarily be achieved.
** AC voltage and frequency range will be programmed
according to the individual country requirements.
INPUT (DC)
Max. recommended PV
power
3100 W
P
Nominal power 2750 W
Voltage range 125 ... 540 V
MPP range 150 ... 450 V
Full power MPP range 150 ... 450 V
Nominal current 10.0 A
Max. current 18.0 A
Stand-by power < 0.2 W
OUTPUT (AC)
Max. power * 2600 W
Nominal power
2500 W
Voltage range ** 184 ... 264 V
Nominal current 11.0 A
Max. current 13.0 A
Nominal frequency 50 Hz
Frequency range ** 47.0 ... 52.0 Hz
Power factor > 0.99 @ nominal power
Total harmonic
distortion (THD)
< 3 % @ nominal power
GENERAL SPECIFICATION
Model name SOLIVIA 2.5 EU G3
Max. efficiency 96.0 %
Efficiency EU 94.4 %
Operating temperature -25 ... +70 °C
Storage temperature -25 ... +80 °C
Humidity 0 ... 98 %
MECHANICAL DESIGN
Size (L x W x D) 410 x 410 x 180 mm
Weight 21.5 kg
Cooling Convection
AC connector Wieland RST25i3S
DC connector pairs 3 Tyco Solarlok
Communication
interfaces
2 Harting RJ45 / RS485
DC disconnector Integrated
Display LCD; 3 LEDs
STANDARDS / DIRECTIVES
Protection degree IP65
Safety class 1
Configurable trip
parameters
Yes
Insulation monitoring Yes
Overload behavior
Current limitation;
power limitation
Safety
EN60950-1; EN50178;
IEC62103; IEC62109-1 / -2
Anti-islanding
protection
DIN VDE 0126-1-1; RD 1663;
RD 661; ENEL G.L. 2010; UTE
15712-1; Synergrid C10/11;
EN 50438; G83/1-1
EMC
EN61000-6-2; EN61000-6-3;
EN61000-3-2; EN61000-3-3
