7.3.7 Submenu T (Total)
Thismenuitemshowscumulatedandmaximum/minimumvaluessincerstuse.
Main menu T - Total statistic
T -> Energy Value (kWh)
T -> Revenue Value
(Euro)
T -> PV-Vol. Max
Value (V)
T -> PV-Cur. Max
Value (A)
T -> PV-Pow. Max
Value (W)
T -> Isolation Max
Value (kOhm)
T -> Isolation Min
Value (kOhm)
T -> Runtime Value (Min)
Down
Down
Down
Down
Down
Down
Down
Up
Up
Up
Up
Up
Up
Down to 2
1
Up to 1
2
Submenu T - Total
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ENTER
Up
Display of the total
energy gain
Display of the total
revenue
Display of the max.
PV cell voltage
Display of the max.
PV cell current
Display of the max.
PV cell power
Display of the largest
insulation resistance
Display of the smallest
insulation resistance
Display of the total operating
time of the solar inverter
7.3.8 Submenu S (Setup)
Thismenuitemisusedforchangingthepresettingsofthesolarinverter.
Main menu S - Setup
S -> LCD-Contrast
0 ... 9
S -> LCD-Backlight
Auto / On
S -> Menu-Mode
Now ... Setup
S -> LCD language
S -> Cash per kWh Value
(Euro) xx,xx
S -> ID-Number
001 ... 254
S -> Solar ISO / GND
S -> Baudrate
2400 ... 38400
Down
Down
Down
Down
Down
Down
Down
Up
Up
Up
Up
Up
Up
Down to 2
1
Up to 1
2
Submenu S - Setup
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ENTER
Up
S -> Time (HH:MM:SS)
Down
ESC
Up
S -> Date
(WD.DD.MM.YYYY)
Down
ESC
Up
S -> Firmware
Down
ESC
Up
Adjustment of the LCD language
Adjustment of the firmware
Adjustment of the brightness of
the LCD display between 0 ... 9
Adjustment of the LCD
background lighting
Selection of the start menu
on restart of the device
Entry of feed-in remuneration in € / kWh
Input of the ID number of the solar inverter
Adjustment of the baud rate
between 2400 ... 38400 Baud
Adjustment of the internal clock
Adjustment of current day of the week and date
ISO / GND Setup Menu
S -> Country settings
Name of country
ESC
Down
Adjustment of the country parameters
Up
To Next Page
