Delta VFD-A Series User Manual

53
NO. Parameter Name Function Explanation Parameter Value
Factory
Setting
10 Accel / decel time Acceleration time 1 d000.1 - d600.0 sec d010.0
11 Setting Deceleration time 1 d000.1 - d600.0 sec d010.0
12 (page 24) Acceleration time 2 d000.1 - d600.0 sec d010.0
13 Deceleration time 2 d000.1 - d600.0 sec d010.0
14
Jog accel / decel
time (page 25)
Jog accel / decel time
select
d000.1 - d600.0 sec
d010.0
15
S-curve (page 26)
S-curve setting d0000 - d0007 d0000
16 Multi-ste
p
s
p
eed Multi-step speed setting 1 d000.0 - d400.0 Hz d000.0
17 operation Multi-step speed setting 2 d000.0 - d400.0 Hz d000.0
18 (page 26) Multi-step speed setting 3 d000.0 - d400.0 Hz d000.0
19 Multi-step speed setting 4 d000.0 - d400.0 Hz d000.0
20 Multi-step speed setting 5 d000.0 - d400.0 Hz d000.0
21 Multi-step speed setting 6 d000.0 - d400.0 Hz d000.0
22 Multi-step speed setting 7 d000.0 - d400.0 Hz d000.0
23
Jog frequency
(page 27)
Jog frequency select d000.1 - d400.0 Hz d006.0
d0000: REV run enable
24
REV run setting
(page 27)
REV run
d0001: REV run disable
d0000
d0000:
Disable over-voltage stall prevention
25
Over-voltage stall
prevention
(page 28)
Over-voltage stall
prevention
d0001: Enable over-voltage stall prevention
d0001
26
Over-current stall
prevention
Over-current stall
prevention during
acceleration
d0050 - d0200 % d0170
27
(page 28)
Over-current stall
prevention during
operation
d0050 - d0200 % d0170
28
DC braking current
setting
DC braking current d0000 - d0100% d0000
29
(page 30)
DC braking time during
start-up
d000.0 - d005.0 sec d000.0
30
DC braking time during
stopping
d000.0 - d025.0 sec d000.0
31
DC braking start-up
frequency
d000.0 - d060.0 Hz d000.0
32
Momentary power
loss protection
Momentary power failure
operation mode selection
d0000: Operation stops after momentary power
Loss.
d0000
(page 31)
d0001:
Operation continues after momentary
power loss. Speed search starts with
the frequency reference value.
d0002: Operation continues after momentary
power loss. Speed search starts with
the minimum output frequency.
