Delta VFD-A Series User Manual

54
NO. Parameter Name Function Explanation Parameter Value
Factory
Setting
33
Maximum allowable
power loss time
d000.3 - d005.0 sec d002.0
34 Minimum base block time d000.3 - d005.0 sec d000.5
35
Speed search
current limit
d0030 - d0200 % d0150
36
Reference freq.
upper / lower limit
Reference frequency
upper limit setting
d000.1 - d400.0 Hz
d400.0
37
setting (page 32)
Reference frequency
lower limit setting
d000.0 - d400.0 Hz d000.0
38
External control 2-wire / 3-wire operation d0000: FWD / STOP, REV / STOP d0000
terminal setting control selection d0001: FWD / REV, RUN / STOP
(page 33)
d0002: 3-WIRE operation control mode
39 Multi-function input Multi-function input 1 d0000: Multi-step speed command 1 d0000
40 terminal setting Multi-function input 2 d0001: Multi-step speed command 2 d0001
41 Multi-function input 3 d0002: Multi-step speed command 3 d0002
(page 34) d0003: Jog frequency reference select
d0004: Accel / decel speed inhibit command
d0005: First and second accel/decel time select
d0006: External baseblock (NO- contact input)
d0007: External baseblock (NC- contact input)
d0008: Up command
d0009: Down command
42
Analog meter
Analog output select d0000:
Analog frequency meter ( 0 to Maximum
Frequency )
d0000
output select
(page 35)
d0001:
Analog current meter ( 0 to 250% of the
rated drive output current )
43
Digital output
frequency multiplier
factor (page 35)
Digital output frequency
multiplier select
d0001 - d0020 d0001
44
Analog output gain
setting (page 36)
Analog output gain select d0001 - d0200 % d0100
45 Multi-function output Multi-function out
p
ut d0000: AC drive operational d0000
terminal setting terminal 1 (MO1) d0001: Pre-set frequency attained
46 (page 37) Multi-function output d0002: Desired frequency attained d0001
terminal 2 (MO2) d0003: Count down complete
d0004: Non-zero speed
d0005: Over-torque detection
d0006: Baseblock indicator
d0007: Low-voltage detect indicator
d0008: AC drive operation mode
d0009: Fault indicator
47
Desired frequency
attained setting
(page 38)
Desired frequency
attained
d000.0 - d400.0 Hz d000.0
