55
NO. Parameter Name Function Explanation Parameter Value
Factory
Setting
48
Analog input for
output frequency
range
Max. output frequency
voltage setting.
d000.0 - d010.0 V d010.0
49
(page 38)
Min. output frequency
voltage setting.
d000.0 - d010.0 V
d000.3
50 Reserved
51 Reserved
52
Motor
current setting
Motor rated current d0030 - d0120 % d0100
53 (page 40) Motor no-load current d0000 - d0099 % d0040
54
Torque
compensation
setting (page 40)
Auto torque
compensation gain
d0000 - d0010 % d0000
55
Slip compensation
(page 41)
Slip correction
compensation
d000.0 - d010.0 % d000.0
56 Reserved
57 Multi-function
d0000: Fault indicator d0000
indication output d0001: AC drive operational
contact d0002: Pre-set frequency attained
RA-RC (NO) d0003: Desired frequency attained
RB-RC (NC) d0004: Non-zero speed
(page 41) d0005: Over-torque detection
d0006: Baseblock indicator
58 Electronic thermal Motor current derated by d0000: Active with standard motor d0002
overload relay
(page 42)
temperature.
d0001: Active with special motor
d0002: Inactive
59 Electronic thermal characteristics selection (42) d0030 d0300 sec d0060
60
Over-torque
detection setting
Over-torque detection
mode select
d0000: Over-torque detection not enabled d0000
(page 43)
d0001:
Over-torque detection during constant
speed operation, operation halted after
over-torque
d0002:
Over-torque detection during constant
speed operation, operation continues
after over-torque detection
d0003:
Over-torque detection during operation,
operation halted after over-torque
d0004:
Over-torque detection during operation,
operation continues after over-torque
detection
61
Over-torque detection d0030 d0200 % d0150
62 Over-torque detection time d000.1 d010.0 sec d000.1
64 Function display Function Display Setting d0000: Displays the actual operating freq. (H) d0000
setting d0001: Displays the user-defined setting (v)
d0002: Displays the value of the internal
(page 45) Counter (c)
65 Coefficient K setting for line speed (page45) d000.1 d200.0 d001.0
