NO. Parameter Name Function Explanation Parameter Value
Factory
Setting
63 Pre-set count down setting (page 44) d0001 - d9999 d0001
66 Count down value setting (page 44) d0001 - d9999 d0001
67 Skip frequencies Skip Frequency 1 d000.0 - d400.0 Hz d000.0
68 1 to 3 setting Skip Frequency 2 d000.0 - d400.0 Hz d000.0
69 (page 46) Skip Frequency 3 d000.0 - d400.0 Hz d000.0
70 Skip Frequency Band d000.1 - d020.0 Hz d000.1
71
PWM Frequency
setting (page 47)
Carrier frequency select
d0001:
fc = 3 KHz, d0002: fc = 6 KHz
d0003: fc = 9 KHz, d0004: fc = 12 KHz
d0005
d0005: fc = 15 KHz
72 Auto reset/restart operation after fault (page47) d0000 - d0010 d0000
73
Fault records
Most recent fault record d0000: Fault records clear (No errors occurred ) d0000
74
(page 48)
Second most recent fault
record
d0001: Over-current (oc) d0000
75
Third most recent fault
record
d0002: Over-voltage (ov) d0000
d0003: Overheat (oH)
d0004: Overload (oL)
d0005: Overload 1 (oL1)
d0006: External fault (EF)
d0007: CPU failure 1 (CF1)
d0008: CPU Failure 3 (CF3)
d0009: Hardware protection failure (HPF)
d0010: O.C. during acceleration (ocA)
d0011: O.C. during deceleration (ocd)
d0012: O.C. during steady state operation (ocn)
d0013: Ground fault or fuse failure (GFF)
d0014-16: Manufacture used diagnostics
d0017: External baseblock (bb)
d0018: Overload 2 (oL2)
d0019-20: Manufacture used diagnostics
76 Keypad lockout
Keypad lockout or reset
d0000:
All parameters can always be set and
read
d0000
(p
a
g
e 48
)
d0001: All parameters are read-only
d0002-d0009: not used
d0010: Resets all parameters to the factory
defaults
77
Baud rate
Data rate in bps
d0000: 1200 baud (Data rate bps) d0002
(p
a
g
e 49
)
d0001: 2400 baud (Data rate bps)
d0002: 4800 baud (Data rate bps)
78
Slave address (page49)
d0000-d0031 d0000
79 Reserved
80 AC motor drive model number and software version (page 50)
