Chapter 4 Parameters



VFD-EL-W

4-86

09.06 Reserved

09.07

Response Delay Time

Unit: 1

Settings

0–200 (1 unit = 2 ms.)

Default: 1

 Sets the response delay time after the AC motor drive receives a communication command as shown in the

following diagram.
