Chapter 4 Parameters
VFD-EL-W
4-106
Parameter
Function Settings Default
End
user’s
master
End
user’s
slave
Note
10.23
Detection
Time of Set
Point
Deviation
Level
1–9999 sec. 10 10 10
decelerate to stop. This
deceleration time is
according to the
Deceleration Time 2 in
Pr.01.12. When the feedback
value is < 2.85 kg, the AC
motor drive starts to run.
10.24
Deviation
Level of Liquid
Leakage
0–50% 0 33 33
Liquid Leakage:
Assume that when the AC
motor drive does not run and
is in a constant pressure
status, the variation of the
feedback value is less than
0.12 kg (3 kg X 4% = 0.12
kg) within 2 seconds. When
the feedback value continues
to decrease to make the
deviation of the set point be
less than 0.99 kg (3 kg X
33% = 0.99 kg), that is, when
the feedback value is less
than 2.01 kg, the AC motor
drive starts to run.
Liquid Usage after Liquid
Leakage:
Assume that when the AC
motor drive does not run and
is in a constant pressure
status, the variation of the
feedback value is higher
than 0.12 kg (3 kg X 4% =
0.12 kg) within 2 seconds,
the AC motor drive starts to
run.
10.25
Liquid
Leakage
Change
Detection
0–100%
(0: Disable)
0 4 4
10.26
Time Setting
for Liquid
Leakage
Change
0.1–10.0 sec.
(0: Disable)
0.5 2 2
10.35
Multi-pump
Control Mode
0: Disable
1: Fixed time circulation
(alternativeoperation)
2: Fixed quantity control (multi-
pump operating at constant
pressure)
0 2 2
10.36 Multi-pump ID
0: Multi-pump control mode is
disabled
1: Master
2–4: Slave
0 1 2
10.37
Multi-pump’s
Fixed Time
Circulation
Period
1–65535 minutes 60 1 1
10.42
Pump’s
Frequency at
Time-out
(Disconnection)
0.00 Hz–FMAX 0.00 60 60
To Next Page
