Delta VFD-M Series User Manual

English-15
Parameter Explanation Settings
Factory
Setting
Customer
Pr.84
Time Duration of 4th
Step Speed
00 to 9999 sec 00
Pr.85
Time Duration of 5th
Step Speed
00 to 9999 sec 00
Pr.86
Time Duration of 6th
Step Speed
00 to 9999 sec 00
Pr.87
Time Duration of 7th
Step Speed
00 to 9999 sec 00
Pr.88
Communication
Address
01 to 254 01
Pr.89 Transmission Speed
00: 4800 bps
01: 9600 bps
02: 19200 bps
03: 38400 bps
01
Pr.90
Transmission Fault
Treatment
00: Warn and Continue Operating
01: Warn and RAMP to Stop
02: Warn and COAST to Stop
03: Keep Operation without Warning
03
Pr.91 Time Out Detection
0.0: Disable
0.1 to 120.0 sec
0.0
Pr.92
Communication
Protocol
00: MODBUS ASCII mode, <7,N,2>
01: MODBUS ASCII mode, <7,E,1>
02: MODBUS ASCII mode, <7,O,1>
03: MODBUS RTU mode, <8,N,2>
04: MODBUS RTU mode, <8,E,1>
05: MODBUS RTU mode, <8,O,1>
00
Pr.93
Accel 1 to Accel 2
Frequency Transition
0.01 to 400.0
0.00: Disable
0.00
Pr.94
Decel 1 to Decel 2
Frequency Transition
0.01 to 400.0
0.00: Disable
0.00
Pr.95 Auto Energy Saving
00: Disable auto energy saving
01: Enable auto energy saving
00
Pr.96
Counter Countdown
Complete
00 to 9999 00
Pr.97
Preset counter
countdown
00 to 9999 00
Pr.98
Total Time Count from
Power On (Days)
00 to 65535 days
Read
Only
Pr.99
Total Time Count from
Power On (Minutes)
00 to 1440 minutes
Read
Only
Pr.100 Software Version ##
Pr.101
Auto Adjustable
Accel/Decel
00: Linear Accel/Decel
01: Auto Accel, Linear Decel
02: Linear Accel, Auto Decel
03: Auto Accel/Decel
04: Linear Accel/Decel Stall Prevention
during Deceleration
00

Delta VFD-M Series Specifications

General

Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
