B.2 All Braking Resistors & Braking Units Use in AC Drives
Note: Please only use DELTA resistors and recommended values. Other resistors and values will void Delta’s
warranty. Please contact your nearest Delta representative for use of special resistors. For instance, in 460 V
series, 100 HP, AC drive has 2 braking units with total of 16 braking resistors, so each braking unit uses 8 braking
resistors. There should be at least 10 cm away from AC drive to avoid possible noise. Refer to the “Braking Unit
Module User Manual” for further detail.
Applicable
Motor
Voltage
HP kW
Full
Load
Torque
KG-M
Equivalent
Resistors
Specification for
Each AC Drive
Braking Unit
Model VFDB
No. of Unit
Used
Braking Resistors
Model No. of Units Used
Braking
Torque
10%ED
Equivalent
Minimum Resistor
Value for Each AC
Drive
1 0.75 0.427
80W 200Ω
BR080W200 1 125
80Ω
2 1.5 0.849
300W 100Ω
BR300W100 1 125
55Ω
3 2.2 1.262
300W 70Ω
BR300W070 1 125
35Ω
5 3.7 2.080
400W 40Ω
BR400W040 1 125
25Ω
7.5 5.5 3.111
500W 30Ω
BR500W030 1 125
16Ω
10 7.5 4.148
1000W 20Ω
BR1K0W020 1 125
12Ω
15 11 6.186
2400W 13.6Ω
2015 1
BR1K2W6P8 2 125
13.6Ω
20 15 8.248
3000W 10Ω
2015 1
BR1K5W005 2 125
10Ω
25 18.5 10.281
4800W 8Ω
2022 1
BR1K2W008 4 125
8Ω
30 22 12.338
4800W 6.8Ω
2022 1
BR1K2W6P8 4 125
6.8Ω
40 30 16.497
6000W 5Ω
2015 2
BR1K5W005 4 125
5Ω
230V Series
50 37 20.6
9600W 4Ω
2015 2
BR1K2W008 8 125
4Ω
1 0.75 0.427
80W 750Ω
BR080W750 1 125
260Ω
2 1.5 0.849
300W 400Ω
BR300W400 1 125
190Ω
3 2.2 1.262
300W 250Ω
BR300W250 1 125
145Ω
5 3.7 2.080
400W 150Ω
BR400W150 1 125
95Ω
7.5 5.5 3.111
500W 100Ω
BR500W100 1 125
60Ω
10 7.5 4.148
1000W 75Ω
BR1K0W075 1 125
45Ω
15 11 6.186
1000W 50Ω
4030 1
BR1K0W050 1
50Ω 50Ω
20 15 8.248
1500W 40Ω
4030 1
BR1K5W040 1
40Ω 40Ω
25 18.5 10.281
4800W 32Ω
4030 1
BR1K2W008 4
32Ω 32Ω
30 22 12.338
4800W 27.2Ω
4030 1
BR1K2W6P8 4
27.2Ω 27.2Ω
40 30 16.497
6000W 20Ω
4030 1
BR1K5W005 4
20Ω 20Ω
50 37 20.6
9600W 16Ω
4045 1
BR1K2W008 8
16Ω 16Ω
60 45 24.745
9600W 13.6Ω
4045 1
BR1K2W6P8 8
13.6Ω 13.6Ω
75 55 31.11
12000W 10Ω
4030 2
BR1K5W005 8
10Ω 10Ω
460V Series
100 75 42.7
19200W 6.8Ω
4045 2
BR1K2W6P8 16
6.8Ω 6.8Ω
Note:
1. Please select the factory default resistance value (Watt) and the frequency value (ED%)
2. If damage resulted in the drive or other equipments due to the fact that the braking resistors and the braking
modules in use are not provided by Delta, the warranty will be void.
3. Take into consideration the safety of the environment when installing the braking resistors.
4. If the minimum resistance value is to be utilized, consult local dealers for the calculation of the Watt figures.
5. Please select thermal relay trip contact to prevent resistor over load.
6. When using more than 2 braking units, equivalent resistor value of parallel braking unit can’t be less than the
value in the column “Equivalent Minimum Resistor Value for Each AC Drive” (the right-most column in
the table).
