Delta VFD022B21A - VFD150 B23 A 15.0 Kw (20.0 HP) 230 V; 3-Phase; VFD150 B43 A 15.0 Kw (20.0 HP) 460 V; 3-Phase; VFD185 B23 A 18.5 Kw (25.0 HP) 230 V; 3-Phase; VFD185 B43 A 18.5 Kw (25.0 HP) 460 V; 3-Phase

VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
C-6
VFD150B23A 15.0 kW (20.0HP) 230V / 3-phase
VFD150B43A 15.0 kW (20.0HP) 460V / 3-phase
VFD185B23A 18.5 kW (25.0HP) 230V / 3-phase
VFD185B43A 18.5 kW (25.0HP) 460V / 3-phase
VFD220B23A 22.0 kW (30.0HP) 230V / 3-phase
VFD220B43A 22.0 kW (30.0HP) 460V / 3-phase
Unit: mm (inches)
13.0 [0.51]
10.0 [0.39]
R
5
.
0
[
R
0.
2
0
]
403.8 [15.90]
384.0 [15.12]
4
2
.
0
[1
.
6
5
]
(
2
X
)
250.0 [9.84]
226.0 [8.90]
2
8
.
0
[
1
.
1
0
]
205.4 [8.08]
10.0 [ 0.39]
