Delta VFD13AMS43ANSAA

Chapter 7 Optional AccessoriesMS300
87
Filter Dimension
EMF11AM21A; EMF10AM23A; EMF6A0M43A
Screw
Torque
M5 * 2
16–20 kg-cm / (13.9–17.3 lb-in.) / (1.56–1.96 Nm)
M4 * 2
14–16 kg-cm / (12.2–13.8 lb-in.) / (1.38–1.56 Nm)
Table 7-47
Unit: mm (inch)
Figure 7-27
