Delta VFD150C43A - Frame E Dimensions; E1: VFD450 C23 A; VFD550 C23 A; VFD750 C23 A; VFD900 C43 A; VFD1100 C43 A

Chapter 1 IntroductionC2000 Series
1-14
Frame E
E1: VFD450C23A; VFD550C23A; VFD750C23A; VFD900C43A; VFD1100C43A
W1
W
H2
H1
H3
D1
D
Unit: mm [inch]
Frame
W H D W1 H1 H2 H3
D1* D2 S1, S2 S3 Ф1 Ф2 Ф3
E1
370.0
[14.57]
-
300.0
[11.81]
335.0
[13.19
589
[23.19]
560.0
[22.05]
528.0
[20.80]
143.0
[5.63]
18.0
[0.71]
13.0
[0.51]
18.0
[0.71]
- - -
D1*: Flange mounting
