Chapter 11 Summary of Parameter SettingsC2000 Plus
11-8
Pr. Parameter Name Setting Range Default
4: Pulse input without direction command (refer to Pr.10-
16 without considering direction), use with PG card
5: Pulse input with direction command (refer to Pr.10-16),
use with PG card
6: CANopen communication card
8: Communication card (does not include CANopen card)
00-21
Operation Command Source
(AUTO)
0: Digital keypad
1: External terminals
2: RS-485 communication input
3: CANopen communication card
5: Communication card (CANopen card not included)
0

00-22 Stop Method
0: Ramp to stop
1: Coast to stop
0

00-23 Motor Direction Control
0: Enable forward / reverse
1: Disable reverse
2: Disable forward
0
00-24
Digital Operator (Keypad)
Frequency Command Memory
Read only
Read
only

00-25 User Defined Characteristics
bit0–3: user-defined decimal place
0000b: no decimal place
0001b: one decimal place
0010b: two decimal places
0011b: three decimal places
bit4–15: user-defined unit
000xh: Hz
001xh: rpm
002xh: %
003xh: kg
004xh: m/s
005xh: kW
006xh: HP
007xh: ppm
008xh: 1/m
009xh: kg/s
00Axh: kg/m
00Bxh: kg/h
00Cxh: lb/s
00Dxh: lb/m
00Exh: lb/h
00Fxh: ft/s
010xh: ft/m
011xh: m
0
