TT-2000, TTD-2000, TT-4000 Ticket Eaters™ by Deltronic Labs June 2019
Performing Functions Without Software
DL Ticket Eater Manager software (sold separately) is the preferred way to manage your
TT-2000 Ticket Eater with AP-100 main logic board. A previous section of this manual
covers the software. Some management functions can also be done without the software
by a special Function mode. This mode uses buttons inside the TT-2000. This section
covers the Function mode.
These procedures use the two buttons mounted in front of the logic board, the SW1
button on the logic board, and the display on the door. To enter the Function mode:
1. Open the top door of the Ticket Eater.
2. While pressing SW1, pull out the safety switch. This turns the Ticket Eater on
with the door open and starts the Function mode.
3. The display will show FUNC0.
4. Use the black and red buttons to change the function number.
5. Press SW1 to select the function.
Increase the function number
Decrease the function number
Print a duplicate receipt
Print an audit report
(see option group 99 5 to reset the audit counters)
Beginning with firmware version 2.10, floor model Ticket Eaters without printers use the
door display to show the audit report. Since the door display is too small to show all the
information at once, it is shown in pieces. Each time you press the red or black button
the next piece is shown. The report shows the information for holes-only tickets and for
each of the eight ticket barcodes. For each of these nine categories a number identifying
the category is shown first, and then the audit count for that category is shown. All audit
counts are 12 digits long and are shown as 3 sets of 4 digits. All 12 digits are shown
including all leading zeros.
Holes-only first 4 digits
Holes-only middle 4 digits
Barcode #1 first 4 digits
Barcode #1 middle 4 digits
