Den-Sin C-200E - Valve, Lance, Hose, and Gun Parts

C-110-170-200E R11 Page 24
Pos Part no.: Qty.: Description:
57
700560061 1 Pump head pre-assembly (Dia 15) C-110E 50/60Hz
700560163 1
Pump head pre-assembly (Dia 15) C-110E 110/220V 50Hz
C-150E 50/60Hz
700560062 1 Pump head pre-assembly (Dia 18) C-170/200E 50/60Hz
1-47 700560160 1 Pump complete C-110E 110V/220V 60Hz ; C-150E 50/60Hz
1-47 700560158 1 Pump complete C-110E 230V 50Hz
1-47 700560002 1 Pump complete C-170E 50/60Hz ; C-200E 60Hz
1-47 700560003 1 Pump complete C-200E 50Hz
Pump spare-parts kit
a.) For All Models
Part no.:/ Kit description Pos: Qty.: Individual components Part no.:
Kit A - 700560004
Pump Valves Kit
(1 SET)
3 6 Valve
4 6 O-Ring
Kit B - 700560011
Oil seals
(1 SET)
10 1 Cap
16 1 O-Ring
30 3 Oil Seal
47 1 Seal
b.) For C-110E & C-150E (Ø15 Piston)
Part no.:/ Kit description Pos: Qty.: Individual components Part no.:
Kit C1 - 700560005
Pistons (Ø15)
(1 SET)
23 3 PISTON Ø15 FOR N3 PUMP
Kit C2 - 700560137
Water seals (Ø15)
(1 SET)
32 3 O-Ring 23.52 x 1
33 3 Gasket DM
8 3 Piston Guide
6 3 Support Ring
7 3 Gasket W1
31 3 Rear Piston Guide
c.) For C-170E & C-200E (Ø18 Piston)
Part no.:/ Kit description Pos: Qty.: Individual components Part no.:
Kit D1 - 700560008
Pistons (Ø18)
(1 SET)
23 3 PISTON Ø18 FOR N3 PUMP
Kit D2 - 700560139
Water seals (Ø18)
(1 SET)
32 3 O-Ring 23.52 x 1
33 3 Gasket DM
8 3 Piston Guide
6
3
Support Ring
7 3 Gasket W1
31 3 Rear Piston Guide
