Den-Sin C-200E - Warranty

C-110-170-200E R11 Page 37
Wiring diagrams (Auto Start Stop 3 phase 220V)
Kit Auto Start Stop
Pos: Part no.: Qty.: Description:
A
2
7005300
05
1
On/Off
Switch w/ Overload Relay
B2
700530610
1
C
ontractor
LC1
-
D25/C
oil
220V
-
23
0V
D2
700530695
1
Timer
E2
700530154
1
Pressure Switch 3/8
”
F2 700530155 1 Pressure Switch 1/4”
G2* 700530613 1 Electrical Box
H2* 700530624 1 SELECTOR SWITCH 230V-500V
- - - -
J2*
700540113
1
NIPPLE 3/8` BSPP M
-
M ZN
K2*
7005
20563
1
ON/OFF SWITCH MOUNTING
-
-
-
-
M2* 700510061 2 BOLT M5 X 20 ALLEN BLACK
N2* 700510051 1 Bolt M6 X 18 HEX
O2* 700510007 1 Locknut M6
P2* 700540317 1 Dowty Seal M6
Q2* 700540186 2 ELBOW 3/8` BSP F-M
R2*
700510136
6
CONTRA NUT 3/8` BSPP BRASS
B2
-
R2
700530643
1
Kit Auto Start Stop
*Not Shown
