4. SPECIFICATION
Description Parameters
AC Power
Worldwide AC Power Supported 110 - 230V, 50/60Hz
In 110VAC supply, the min voltage ranges from 92V to max 126V
In 230VAC supply, the min voltage ranges from 184V to max 253V
Power Consumption
< 30W
Frequency Response
20-40KHz -0.2dB
THD+N
≤0.0010% (1KHz A Weighted)
Output (RCA)
2.3(+/-10%) V RMS(1KHz)
Output (XLR)
4.6(+/-10%) V RMS(1KHz)
Supported Format (DSD)
DSD64 All Input
DSD64 – DSD1024 USB & I²S Only
Supported Format (PCM)
24bit/44.1, 48, 88.2, 96, 176.4, 192 kHz All Input
44.1 – 1536 kHz USB & I²S Only
S/N Ratio
115dB(RCA), 114dB(XLR)
Dynamic Range
>132dB
Stereo Crosstalk
-110dB
Dimension
430*380*105 mm
Weight
19.0kg
