MATRIX control panel Operating MATRIX control panel
PR-2011-0110-GB • Subject to modifications • R9-03-2016 73
Fans ➜ Factor
The submenu "Factor" indicates the speed relationship between master and
slave fan using a multiplicative factor. This submenu is available only if the slave
control using factor was selected in the submenu "Control Mode" .
The slave fan speed is calculated as follows:
Speed of the slave fan = speed of the master fan * factor
If the factor = 1 then both fans are operated at the same speed
Fans ➜ fan speed offset
The submenu "speed offset" indicates the speed relationship between master
and slave fan using an offset in percent. This submenu is available only if the
slave control using peed offset was selected in the submenu "control mode".
The slave fan speed is calculated as follows:
Speed of slave fan [%] = speed of master fan [%] + speed x offset [%]
If the offset = 0 then both fans run at the same speed
-------- Without supply-air fan Speed.OP Assignment of fan speed using control
panel
Offset Supply-air fan follows extract-air fan with
speed offset
Speed.OP Assignment of fan speed using control
panel
Factor Supply-air fan follows extract air fan with
factor
Speed.OP Assignment of fan speed using control
panel
Speed ext. Fan speed setting with external 0-10V in-
put
-------- Without extract-air fan
Speed ext. Fan speed setting with external 0-10V in-
put
Offset Extract-air fan follows supply-air fan with
speed offset
Speed ext. Fan speed setting with external 0-10V in-
put
Factor Extract-air fan follows supply-air fan with
factor
-------- Without supply-air fan Speed
ext.
Fan speed setting with external 0-10V in-
put
Offset Supply-air fan follows extract-air fan with
speed offset
Speed
ext.
Fan speed setting with external 0-10V in-
put
Factor Supply-air fan follows extract air fan with
factor
Speed
ext.
Fan speed setting with external 0-10V in-
put
Supply-air fan Extract-air fan
Value range: 0 to 2
Adjustable steps: 0.01
Factory setting: 1
