MATRIX control panel Menu Structure OP5xx
PR-2011-0110-GB • Subject to modifications • R9-03-2016 89
9 Menu Structure OP5xx
All possible menus are shown in this menu structure. According to the configuration of the controller
some menus can exclude one another or not appear at all.
1)
This menu is not available if MATRIX 4700 controls is used for standard and low-profile air handling units.
2)
This menu is only available if MATRIX 4700 controls is used with standard and low-profile air handling units.
Basic menu
(
→ 38)
−
Setpoint
Room temperature
Home screen (alternative)
(
→ 39)
−
Entering setpoint
Supply-air temperature
Fan mode
(
→ 40)
−
OFF
Automatic
Auto (mute)
Speed xx % or stage x
plant/fan
(
→ 41)
−
OFF
On - manual
On - air quality
Fan speed (
→ 42)
−
Speed xx %
Supply-air duct pressure/
extract-air duct pressure
(
→ 42)
−
Pressure in Pa
Supply air volume flow/
Extract air volume flow(
→ 43)
−
Volume flow in m³/h
Operating mode (
→ 43)
−
Normal operation
Economy mode
Clock Timer
(Preference)
Bypass
Controller mode (
→ 44)
−
Heating only
Cooling only
Automatic
Passive Cooling
Secondary-air louvre (
→ 45)
−
Change position in %
Adjust louvre angle (
→ 45)
−
Adjust louvre angle in degrees
Mixing-air damper position (→ 46)
−
Air volume flow in %
Outside air flow (
→ 46)
−
Change position in %
Outside air automatic (
→ 46)
−
Recirculating air
Mixed air
FOS Test menu (
→ 46)
−
Only with LON module -
See MATRIX.LON operation
manual
Fast aerate
1)
(→ 46)
−
Enter time for fast aerate
Basic ventilation
(
→ 47)
−
On
Automatic
Room air flow
(SWIRL-function)
(
→ 47)
−
Automatic
Manual
Turbo
Breath
Other menus
(
→ 49)
−
Error list (only for errors)
(
→ 49)
−
e.g. sensor errors
−
Clock timer (→ 50)
−
Week programme (→ 51)
−
Activation
−
Delete program
−
All week days
−
Monday - Friday
−
Saturday - Sunday
−
Monday
...
−
Sunday
