20
FT Range SP20001_REV_2
1.03 Chassis - RH Side Plate
Item No. Part No. Description Quantity
1 J209254 Side Plate RH 1
2 J20023 Unit Limiting Stud 1
3 229741 Buffer Block 1
4 229742 Buffer 1
5 SP03003 Washer M6 Toothed 2
6 SP01008 Hex Set Screw M6 x 16 3
7 J209229 Clutch Rod Stop 1
8 J209078 Retaining Screw Plate 1
9 SP01016 Button Head M6 x 12 2
10 J20207 Stud Brake Band Cover 2
11 J20237 Unit Bearing Stud 1
12 SP02006 Nut M8 Nyloc 4
13 SP02004 Nut M6 Nyloc 1
14 SP03010 Washer M6 Form A 1
15 SP02008 Nut M10 Nyloc 1
16 SP03008 Washer M8 Form A 3
17 SP03011 Washer M10 Form A 1
7
15
17
8
10
10
6
5
12
16
6
1
4
3
12
12
16
9
11
12
16
13
14
2
