Dennis FT 430 - Page 32

32
FT Range SP20001_REV_2
8.05 Rear Roller - RH Differential Assembly
1
6
4
5
2
4
3
7
1
2
3
Item No. Part No. Description Quantity
1 800006 17” Annular Gear Shaft Assy 1
1 800015 20” Annular Gear Shaft Assy 1
1 800040 24” Annular Gear Shaft Assy 1
2 J20420 Annular Gear Case 1
3 J17421 17” Annular Gear Case Tube 1
3 J20421 20” Annular Gear Case Tube 1
3 J24421 24” Annular Gear Case Tube 1
4 J20424 Washer Annular 1
5 J20426 Bush Annular Gear Tube 2
6 J20432 Oil Plug (14” BSP) 1
7 J20482 Seal Single Lip R21 1
Not Shown
- J20430 Caphead M6 x 30 (For Assy with 8.04) 4
- J20494 Gasket Rear Roller (For Assy with 8.04) 1
