FRONT PANEL
3
Display
 Decoder indicators
These light when the respective decoders are operating.
 Input signal indicators
 Information display
The input source name, surround mode, setting values and other
information are displayed here.
 Front speaker indicator
This lights according to the setting of the front speakers.
 Master volume indicator
 Sleep timer indicator
This lights when the sleep mode is selected
 MUTE indicator
This lights when the mute mode is selected
 Surround back indicator
This lights when audio signals are being output from the surround
back speakers (vpage 86).
 Input mode indicators
Set the audio input modes for the different input sources
 RESTORER indicator
This lights when the RESTORER mode is selected
 HDMI indicator
This lights when playing using HDMI connections.
 Tuner reception mode indicators
These light according to the reception conditions when the input
source is set to “TUNER”.
STEREO : In the FM mode, this light when receiving stereo
broadcasts.
TUNED : Lights when the broadcast is properly tuned in.
AUTO : This light when in the auto tuning mode.
REAR PANEL

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
