AVR-1403/483
Audio Section
Power Amplifier
Rated output: Front: 60W+60W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (Europe & China Models)
70W+70W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (U.S.A. & Canada Models)
90W+90W(6Ω/ohms, 1kHz with 0.7% T.H.D) (Europe Model)
100W+100W(6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A. & Canada Models )
100W+100W(6Ω/ohms, EIAJ) (China Model )
Center: 60W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (Europe & China Models)
70W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (U.S.A. & Canada Models)
90W(6Ω/ohms, 1kHz with 0.7% T.H.D) (Europe Model)
100W(6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A. & Canada Models )
100W(6Ω/ohms, EIAJ) (China Model )
Surround: 60W+60W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (Europe & China Models)
70W+70W(8Ω/ohms, 20Hz~20kHz with 0.08% T.H.D) (U.S.A. & Canada Models)
90W+90W(6Ω/ohms, 1kHz with 0.7% T.H.D) (Europe Model)
100W+100W(6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A. & Canada Models )
100W+100W(6Ω/ohms, EIAJ) (China Model )
Output terminals: Front: A or B 6 to 16Ω/ohms
A+B 12 to 16Ω/ohms
Center/Surround: 6 to 16Ω/ohms
Analog
Input sensitivity/input impedance: 200mV/47kΩ./kohms
Frequency response: 10Hz~100kHz: +1, -3dB (TONE DEFEAT ON)
S/N ratio: 98dB (IHF-A weighted) (TONE DEFEAT ON)
′
Standard video jacks
Input/output level and impedance : 1Vp-p,75Ω/ohms
Frequency response: 5Hz~10MHz . +1, -3dB
Tuner section
Receiving range: [FM] (note: µV at 75Ω/ohms, 0dBf =1x10
-15
W) [AM]
U.S.A., Canada Models: 87.50MHz~107.90MHz 520kHz~1710kHz
Europe & China Models: 87.50MHz~108.00MHz 522kHz~1611kHz
Usable sensitivity: 1.0µV (11.2dBf) 18µV
50 dB quieting sensitivity: MONO 1.6µV (15.3dBf)
STEREO 23µV (38.5dBf)
S/N ratio: MONO 80dB (IHF-A weighted)
STEREO 75dB (IHF-A weighted)
Total harmonic distortion: MONO 0.15% (1kHz)
STEREO 0.3% (1kHz)
General
Power supply:
U.S.A., Canada Models AC120V,60Hz
Europe Model AC230V,50Hz
China Model AC220V,50Hz
Power consumption: 3.7A (USA & Canada model), 200W (Europe & China model)
Maximum external dimensions: 434 (W) x 147 (H) x 417 (D) mm (17-3/32” x 5-25/32” x 16-7/16”)
Mass: 9.8kg (20 lbs 9.7 oz)
Remote control unit (RC-896)
Batteries: R6P/AA Type (two batteries)
External dimensions: 54 (W) x172.5 (H) x 29 (D) mm (2-1/8” x 6-51/64” x 1-9/64”)
Mass: 120g (Approx. 4.2 oz) (including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
SPECIFICATIONS
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
