AVR-1403/483
PARTS LIST OF P.W.B. UNIT ASS'Y
MAIN P.W.B. ASS'Y
Ref. No. Part No. Part name Remarks
RESISTORS GROUP
R104C 963 9005 451 Metal film 5.6 kohm 1W
R104FL,104FR 963 9005 451 Metal film 5.6 kohm 1W
R104SL,104SR 963 9005 451 Metal film 5.6 kohm 1W
R105C 963 9005 451 Metal film 5.6 kohm 1W
R105FL,105FR 963 9005 451 Metal film 5.6 kohm 1W
R105SL,105SR 963 9005 451 Metal film 5.6 kohm 1W
R106C 963 9005 464 Metal film 4.7 ohm 1W
R106FL,106FR 963 9005 464 Metal film 4.7 ohm 1W
R106SL,106SR 963 9005 464 Metal film 4.7 ohm 1W
R107C 963 9005 464 Metal film 4.7 ohm 1W
R107FL,107FR 963 9005 464 Metal film 4.7 ohm 1W
R107SL,107SR 963 9005 464 Metal film 4.7 ohm 1W
R108C 963 9005 477 Metal film 0.22 ohm 1W
R108FL,108FR 963 9005 477 Metal film 0.22 ohm 1W
R108SL,108SR 963 9005 477 Metal film 0.22 ohm 1W
R109C 963 9005 477 Metal film 0.22 ohm 1W
R109FL,109FR 963 9005 477 Metal film 0.22 ohm 1W
R109SL,109SR 963 9005 477 Metal film 0.22 ohm 1W
R110C 963 9005 477 Metal film 0.22 ohm 1W
R110FL,110FR 963 9005 477 Metal film 0.22 ohm 1W
R110SL,110SR 963 9005 477 Metal film 0.22 ohm 1W
R111C 963 9005 477 Metal film 0.22 ohm 1W
R111FL,111FR 963 9005 477 Metal film 0.22 ohm 1W
R111SL,111SR 963 9005 477 Metal film 0.22 ohm 1W
R118C 963 9005 480 Metal oxide 10 ohm 1W(NB)
R118FL,118FR 963 9005 480 Metal oxide 10 ohm 1W(NB)
R118SL,118SR 963 9005 480 Metal oxide 10 ohm 1W(NB)
R119C 963 9005 480 Metal oxide 10 ohm 1W(NB)
R119FL,119FR 963 9005 480 Metal oxide 10 ohm 1W(NB)
R119SL,119SR 963 9005 480 Metal oxide 10 ohm 1W(NB)
R141,142 963 9005 477 Metal film 0.22 ohm 1W
R148,149 963 9005 477 Metal film 0.22 ohm 1W
R151 963 9005 493 Metal film 68 ohm 1/4W
R154 963 9005 503 Metal film 2.2 Mohm 1/2W for E3,EU
R181 963 9005 516 Metal film 4.7 ohm 1W
R184 963 9005 529 Metal oxide 10 ohm 1W(NB)
R185 963 9005 532 Metal film 1 ohm 1/4W
OTHER PARTS GROUP
JK101 960 0216 208 4P Terminal LOCK TYPE
JK102 963 0093 802 6P Terminal BINDING
TYPE
JK103 960 0216 208 4P Terminal LOCK TYPE
!
JK104 963 0093 909 AC Outlet for E3,EU
Note :Thesymbolsinthecolumn"Remarks"indicate
thefollowingdestinations.
E3 :U.S.A.&Canadamodel
EU :U.S.A.model(AVR-483)
E2 :Europemodel
E1C :Chinamodel(AVR1403,AVR483)
