Denon AVR-1403 Service Manual

4
AVR-1403/483
CPU P.W.B. ASS'Y
CNT P.W.B. ASS'Y
PRE-AMP P.W.B. ASS'Y
DSP P.W.B. ASS'Y
Ref. No. Part No. Part name Remarks
SEMICONDUCTORS GROUP
IC231 963 0093 608 IC M62446AFP
RESISTORS GROUP
R231,232 963 9005 600 Metal film 100 ohm 1W
R271 963 9005 613 Metal film 220 ohm 1W
R274 963 9005 613 Metal film 220 ohm 1W
OTHER PARTS GROUP
JK301 963 0084 206 3P pin jack Gold
Ref. No. Part No. Part name Remarks
RESISTORS GROUP
R405 963 9005 545 Metal film 100 ohm 1/4W
R413 963 9005 558 Metal film 220 ohm 1/4W
R416 963 9005 561 Metal film 680 ohm 1/4W
R430 963 9005 545 Metal film 100 ohm 1/4W
R434 963 9005 545 Metal film 100 ohm 1/4W
R901,902 963 9005 574 Metal film 470 ohm 2W
OTHER PARTS GROUP
CP651  
JK901 960 0176 306 Headphone jack Gold
Ref. No. Part No. Part name Remarks
RESISTORS GROUP
R509C 963 9005 587 Metal film 1.2 kohm 1/4W
R509FL,509FR 963 9005 587 Metal film 1.2 kohm 1/4W
R509SL,509SR 963 9005 587 Metal film 1.2 kohm 1/4W
R511C 963 9005 590 Metal film 47 ohm 1/4W
R511FL,511FR 963 9005 590 Metal film 47 ohm 1/4W
R511SL,511SR 963 9005 590 Metal film 47 ohm 1/4W
Ref. No. Part No. Part name Remarks
SEMICONDUCTORS GROUP
IC817 
RESISTORS GROUP
R803 
CAPACITORS GROUP
C812 
C813 
C814 
OTHER PARTS GROUP
L806 
Note :Thesymbolsinthecolumn"Remarks"indicate
thefollowingdestinations.
E3 :U.S.A.&Canadamodel
EU :U.S.A.model(AVR-483)
E2 :Europemodel
E1C :Chinamodel(AVR1403,AVR483)
