Denon AVR-1509 Service Manual

106
AVR-1709/1609/1519/1509/689/589, AVC-1509
C1063 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1064 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1065 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1066 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1067 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1068 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1070 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1071 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1072 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1073 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1074 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1075 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1076 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1077 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1078 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1079 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1080 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1081 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1082 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1083 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1084 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1085 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1086 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1088 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1090 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1092 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1093 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1094 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1098 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1103 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C1104 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1105 00D9639005820 C,ELECT 22UF-M/16V D040220083070S
C1106 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1107 00D9639005820 C,ELECT 22UF-M/16V D040220083070S
C1108 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1109 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1113 00D9630234108 C,FILM 0.1UF-J/50V D020104167050S
C1114 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1115 00D9630130105 C,FILM 1UF-K/63V D020105078060S
C1116 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1117 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1118 00D9630024907 C,ELECT 1000UF-M/6.3V D040102081060S
C1120 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1121 00D9630234108 C,FILM 0.1UF-J/50V D020104167050S
C1122 00D9630234108 C,FILM 0.1UF-J/50V D020104167050S
C1123 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1124 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1125 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1126 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1127 00D9639005820 C,ELECT 22UF-M/16V D040220083070S
C1128 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1129 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
C1130 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
C1131 00D9630324403 C,ELECT 33UF-M/35V D040330085050S
C1132 00D9630144706 C,FILM 0.01UF-J/50V D020103167050S
C1133 00D9630144706 C,FILM 0.01UF-J/50V D020103167050S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
