Denon AVR-1509 Service Manual

113
AVR-1709/1609/1519/1509/689/589, AVC-1509
CP402 nsp CN.WAFER 3P L102526700300S
CP705 nsp CN.WAFER 3P L101200100310S
z F401D 00D9630104801 FUSE T3.15A /250V N751223151110S
F401DA nsp HOLDER,FUSE CLIP G645000050010S
F401DB nsp HOLDER,FUSE CLIP G645000050010S
z F402D 00D9630104801 FUSE T3.15A /250V N751223151110S
F402DA nsp HOLDER,FUSE CLIP G645000050010S
F402DB nsp HOLDER,FUSE CLIP G645000050010S
L401SBL nsp COIL INDUCTOR 0.5UH D330R50000000S
L401SBR nsp COIL INDUCTOR 0.5UH D330R50000000S
TP401,402 nsp CN.WAFER 3P ANGLE L101530150310S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
